Auto 2-sided Printing Printer
- A4 print speed up to 34 ppm (Black)
- WiFi, AirPrint, Mopria, WiFi Direct, LAN, NFC card reader, USB 2.0
- Auto 2-sided (Duplex) printing, 50 sheets dual CIS Auto-Document Feeder (ADF), 2.7” Colour LCD touchscreen
- Full capacity toner included. Yield up to 1200 pages (black)*
- Compatible with Mobile Connect app
Information
Overview
Double the print, half the paper
Automatic duplex printing uses up to 50% less paper.
Quiet as a whisper
Reduce noise and energy consumption with Quiet Mode.
Less reloads reduced waste
Lower your usage by optimising the resolution for less toner reloads — thus cutting down the amount of plastics used.
A more efficient use of resources
Maximise every sheet of paper with N-in-1 printing giving you up to 4 pages per side.
Specifications
Basic Specs
Functions
Print, Scan, Copy, Fax
Printer Type
Laser Printer
Product Dimensions (Width X Depth X Height)
410 mm × 399 mm × 319 mm
Weight
10.7 kg
Print Speed
Up to 34 (A4) / Up to 36 (Letter) ppm
Paper Type
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env.Thick
Paper Size
A4, Letter, B5 (JIS), B5 (ISO), A5, A5 (Long Edge), B6 (JIS), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch
(Legal and Folio size paper are supported only in some countries.)
Maximum Paper Capacity
Up to 250 sheets of 80 gsm plain paper
Resolution
Up to 1200 x 1200 dpi
2-Sided (Duplex) - Printing Paper Type
Plain Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) - Paper Size
A4
Paper handling
Tray #1 - Maximum Paper Capacity
Up to 250 sheets of 80 gsm plain paper
Manual Feed Slot - Maximum Paper Weight
60 to 230 gsm (16 to 61 lb)
Manual Feed Slot - Maximum Paper Capacity
1 sheet
Automatic Document Feeder (ADF) Maximum Paper Capacity
Up to 50 sheets of 80 gsm plain paper
Paper Output
Up to 120 sheets of 80 gsm plain paper (face down delivery to the face down output paper tray)
1 sheet (face up delivery to the face up output tray)
Copy
Enlarge/ Reduce
25% to 400% (in increments of 1%)
Resolution
Up to 600 x 600 dpi
Scan
Resolution - Interpolated
Up to 19,200 x 19,200 dpi (interpolated) (Windows Only)
Resolution - Scanner Glass
Up to 1200 x 1200 dpi
Resolution - Automatic Document Feeder (ADF)
Up to 600 x 600 dpi
Fax
Compatibility
ITU-T Super G3
Modem Speed
33.6 Kbps
Memory Transmission
Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
Out of Paper Reception
Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
PC Fax - Sending
Yes (Mono)
PC Fax - Receiving
Yes (Mono)
Connectivity
Connectivity
Hi-SpeedUSB2.0, Ethernet 10Base-T/100Base-TX, IEEE 802.11a/b/g/n (Infrastructure Mode), IEEE 802.11a/g/n (Wi-Fi Direct), NFC
Network
Wireless Network Security
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)
*Wi-Fi Direct supports WPA2-PSK (AES) only.
Display & Memory
Display Type
2.7" Colour Touchscreen LCD
Memory Capacity
256 MB
Operation
Power Source
220 - 240 V AC 50/60 Hz
Power Consumption - Ready
Approximately 43 W
Power Consumption - Sleep
Approximately 4.1 W
Power Consumption - Power Off
Approximately 0.06 W (For Taiwan)
Approximately 0.08 W (Except for Taiwan)
Supported Operating Systems
Supported OS
Windows 10, 11
Server 2012, Server 2012 R2, Server 2016, Server 2019, Server 2022
Show More
Show Less
